Mini Corn Silage Harvester Self-propeled
Product Advantages:
Senrui Zhenghe series 4QZ-2600 self-propelled silage machine has a compact structure, small turning radius, easy operation and reliable quality. It adopts a horizontal clamping feeding device to improve the reliability of the whole machine, more convenient maintenance, and four-roller feeding. The blade uses 18 double-row herringbone-shaped moving knives, an integrated spindle design, and a double-edged fixed knife design that can be reversed and replaced. It is equipped with an automatic knife sharpening function as standard.
Product Details:
★ Grain crushing: high-strength grain crushing rollers with a grain crushing rate of more than 97%, which improves the palatability and feeding rate of livestock.
★ Throwing assembly: The throwing barrel rotation adopts a worm gear mechanism, which can achieve 200° rotation, effectively stop the spray barrel angle, and make the spraying angle more stable.
★ Powertrain: Full diesel 220 horsepower, PTO intelligent fuel-saving control, with light load, medium load, heavy load switching function, four-wheel drive, etc.
★ Control/hydraulic: standard air conditioning, electronic operating handle, suspension seat, more comfortable driving, cab host standard large-screen LCD display and operation monitoring system, improve the operating safety, reliability, and intelligence of the machine, the whole machine is hydrostatically driven, and the driving is more comfortable.
Product parameter:
Projects | unit | Design value |
Model Name | / | 4QZ-2600 Self-propelled Green Forage Harvester |
Form of Construction (Hook-up) | / | Self-propelled |
Working condition external dimensions (L*W*H) | mm | 6250×2800×5000 |
structural quality | kg | 7040 |
Matching power range | kW | 191.5 |
Matching engine rated speed | r/min | 2200 |
Cutting width | mm | 2620 |
Crop collecting header type | / | Straight cutting table |
Header cutter type | / | Disc cutter |
Feeding mechanism type | / | Feeding roller |
Number of feeding mechanisms | / | 4 |
Straw chopping mechanism type | / | Drum type |
Grain crushing mechanism type | Roller type | |
Speed Shift | / | Manual speed shift |
Drive mode | / | Hydraulic drive |
Brake type | / | Disc |
Steering wheel track | mm | 1600 |
Guide wheel tire specifications | / | 10.0/80-18 |
Driving wheel track | mm | 1570 |
Driving wheel tire specifications | / | 400/70R24 |
Wheelbase | mm | 2355 |
Operating speed range | km/h | ≤7 |
Design cutting length | mm | 20 |
