Tractor Silage Chopper Machine
Product description:
The Senrui Dahe series 4QX-2400A mounted silage harvester features a novel design that enables fully non-row harvesting. Compact, highly efficient, versatile, energy-efficient, and agile, it is not restricted by crop row spacing, combining high efficiency with safe and reliable performance. It can be used with any tractor or harvester that meets the requirements. It can simultaneously complete multiple operations on silage crops, including cutting, sequential feeding, uniform chopping, and loading.
Product characteristics:
★ Grain Crushing: High-strength, quick-change double-roller crushing rollers achieve a grain crushing rate of over 97%, improving livestock palatability and feed intake.
★ Automatic blade sharpening eliminates the time-consuming and labor-intensive blade sharpening problem, significantly reducing maintenance time and improving efficiency.
★ The spray barrel rotates using a worm gear mechanism, allowing for ±180-degree rotation, effectively locking the barrel angle for a more stable spraying angle.
★ The throwing mechanism quickly and accurately throws chopped material into the accompanying collection bin, with adjustable throwing direction, angle, and position.
Product parameter:
Projects | Unit | Design Value |
Model Name | / | 4QX-2400 type backpack green fodder harvester |
Form of Construction (Hook-up) | / | Disc type (suspended) |
Working condition external dimensions (L*W*H) | mm | 4900×2450×4930 |
structural quality | kg | 2108 |
Matching power range | kw | 117.6~132.3 |
Effective harvesting width of the cutter | mm | 2220 |
Crop collection cutter type | / | Straight cutting table |
Cutting table cutter type | / | Disc cutter |
Feeding mechanism type | / | Feed rollers |
Number of institutions fed | / | 2 pair |
Chopping mechanism rotor diameter | mm | 895 |
Rated spindle speed | r/min | 850/1000 |
Maximum throwing height | mm | 4850 |
Throwing Minimum Height | mm | 4500 |
Swivelling angle of throwing cylinder | ° | ±180 |
Throwing maximum horizontal distance | m | 12 |
Operating speed range | km/h | 3~6 |
Mean geometric height of material | mm | 10 |
Standard Grass Length Ratio | % | 95 |
Number of moving knives | Piece | 12 |
operating method | / | fully hydraulic |
Adaptation to crop height | mm | 400-5000 |
efficiency of production | t/h | 15~30 |
