Alfalfa Silage Harvester For Farm Use
Product advantages:
Senrui Zhenghe series 4QZ-2000C self-propelled green fodder harvester. The equipment is small in size, high in efficiency, widely used, low in energy consumption, flexible in action, and not restricted by crop row spacing. Equipped with a grain crushing function, the crushing rate is as high as over 97%. The 175 horsepower engine is powerful, and the four-wheel drive system has strong passability in mountainous and hilly areas. It combines the advantages of high operating efficiency and safe and reliable performance.
Product details:
● Short body, small turning radius, flexible and convenient operation, suitable for small and medium-sized plots, mountainous areas, hills, terraces and other regional operations.
● Cutting feeding assembly: two-roller feeding chamber, segmented design, more convenient maintenance, using double disc saw blade cutter, can adapt to all rod-shaped forage crops non-row operation.
● Spray barrel assembly: The spray barrel rotation adopts worm gear mechanism, which can rotate ±180°, effectively locks the spray barrel angle, and makes the spraying angle more stable.
● Powertrain: 175 horsepower engine, sufficient horsepower, strong power, four-wheel drive system, high passability in mountainous areas and hills.
Product Parameters：
| Project | Unit | Design value |
| Model Name | / | 4QZ-2000C Self-propelled Green Forage Harvester |
| Form | / | Self-propelled |
| Working state dimensions (L×W×H) | mm | 5400×2200×3750 |
| Construction Quality | kg | 4420 |
| Matching engine rated power | kw | 129 (National Level 4) |
| Matching engine rated speed | r/min | 2300 |
| Cutting width | mm | 2020 |
| Crop collecting header type | / | Straight cutting table |
| Header cutter type | / | Disc cutter |
| Feeding mechanism type | / | Feeding roller |
| Number of feeding mechanisms | / | 1pair |
| Straw chopping mechanism | Disc | |
| Grain crushing mechanism | / | Roller type |
| Cab type | Simple | |
| Speed Shift | Manual speed shift | |
| Drive mode | / | Hydraulic drive |
| Brake type | / | Disc |
| Steering wheel track | mm | 1210 |
| Guide wheel tire specifications | / | 10.0/80-12 |
| Driving wheel track | mm | 1230 |
| Driving wheel tire specifications | / | 11.5/80-15.3 |
| Wheelbase | mm | 2190 |
| Operating speed range | km/h | ≤6 |
| Design cutting length | mm | 20 |
