Factory Supply 4Qz-1600 High Performance 175Hp Diesel Self Propelled Corn Stalks Silage Harvester Suitable For Livestock Feed
Product introduction：
The 4QZ-1600 self-propelled forage harvester is tailor-made for small to medium-sized farms. Powered by a diesel engine, this compact and agile machine operates independently—eliminating the need for an additional tractor—to complete the entire process of harvesting, feeding, chopping, and discharging. It is suitable for a variety of silage crops, including corn stalks, sorghum, and alfalfa. The unit supports non-row-specific harvesting, features an adjustable header height and variable chop length, and ensures uniform forage processing. Its anti-clogging feeding mechanism effectively minimizes downtime caused by blockages. With excellent off-road capability, it performs reliably in muddy fields and on slopes, while the fully hydraulic control system is simple and easy to master. Compact in design, easy to maintain, and highly cost-effective, the 4QZ-1600 is an ideal choice for silage harvesting on overseas farms, backed by comprehensive after-sales service and spare parts support.
Product features ：
·Features an independent, self-propelled design that eliminates the need for a tractor; supports non-row-specific harvesting and is suitable for various silage crops, including corn stalks, sorghum, and alfalfa.
·Equipped with a four-wheel-drive chassis, the machine features a compact and agile design with a small turning radius, allowing for stable operation in hilly terrain, on slopes, and in small, muddy agricultural plots.
·Equipped with a disc-type chopping system, the machine offers multi-stage adjustable chop lengths, ensuring uniform forage cutting and enhancing the quality of silage fermentation.
·Features an anti-clogging feed mechanism and full hydraulic control, ensuring simple operation and rapid discharge.
·The entire unit is designed for easy containerized shipping; it is simple to maintain, features a reliable supply of spare parts, and represents a highly cost-effective silage equipment solution for livestock farms.
Product parameter:
Projects | Unit | Design value |
Model Name | / | 4QZ-1600 self-propelled forage harvester |
Formality | / | Self-propelled |
Working condition external dimensions (L*W*H) | mm | 5200*1950*4000 |
Structural quality | kg | 3650 |
Matching Engine Rated Power | kw | 103 |
Matching engine rated speed | r/min | 2400 |
Cut width (of a page) | mm | 1480 |
Crop collection cutter type | / | Straight cutting table |
Cutting table cutter type | / | Disc cutter |
Feeding mechanism type | / | Feed rollers |
Number of institutions fed | / | 1 pair |
Chopping mechanism type | / | Disc |
Transmission mode | / | Manual gearbox |
Drive method | / | Mechine |
Brake type | / | Drum |
Guide wheel spacing | mm | 1180 |
Guide wheel tyre specifications | / | 10.0/80-12 |
Driving Wheel Distance | mm | 1230 |
Driving wheel tyre specifications | / | 11.5/80-15.3 |
Wheelbases | mm | 2190 |
Operating speed range | km/h | ≤6 |
Design Cutting Length | mm | 20 |
