2.050m Wheeled Corn And Alfalfa Straw Forage Harvester
Product Introduction:
The Senrui Zhenghe Series 4QZ-2100 self-propelled forage harvester is independently developed and manufactured by our company. Developed through years of practical experience and the perfect integration of the latest technologies, this machine features 18 double-row herringbone-shaped blades, an integrated main shaft design, reversible and interchangeable double-edged fixed blades, and comes standard with automatic blade sharpening. It is powered by a 220-horsepower diesel engine, features intelligent fuel-saving PTO control, light, medium, and heavy load switching, and a four-wheel drive system. The machine also includes a built-in kernel crushing device, achieving a crushing rate exceeding 97%.
Product Details:
☆ The machine features a compact structure, a small turning radius, flexible and easy operation, and reliable quality.
☆ Kernel Crushing: The high-strength double-roller kernel crushing device achieves a kernel crushing rate of over 97%, improving livestock palatability and feed intake.
☆ Feed Bin Assembly: The built-in loading bin allows for easy rear-end unloading, and the added secondary lift function adapts to various feed handling vehicles, making unloading even more convenient.
☆ Controls/Hydraulics: Standard air conditioning, electronic operating handles, and a suspended seat provide a more comfortable ride. The cab main unit is equipped with a large LCD display and an operation monitoring system, enhancing the machine's operational safety, reliability, and intelligence. The entire machine features a hydrostatic drive for a more comfortable ride.
Product parameter:
Projects | unit | Design value |
Model Name | / | 4QZ-2100 Self-propelled Green Forage Harvester |
Form of Construction (Hook-up) | / | Self-propelled |
Working condition external dimensions (L*W*H) | mm | 5560*2200*4000 |
structural quality | kg | 6400 |
Matching power range | kW | 161.5 |
Matching engine rated speed | r/min | 2300 |
Cutting width | mm | 2050 |
Crop collecting header type | / | Straight cutting table |
Header cutter type | / | Disc cutter |
Feeding mechanism type | / | Feeding roller |
Number of feeding mechanisms | / | 4 |
Straw chopping mechanism type | / | Drum type |
Grain crushing mechanism type | Roller type | |
Speed Shift | / | Manual speed shift |
Drive mode | / | Hydraulic drive |
Brake type | / | Disc |
Steering wheel track | mm | 1600 |
Guide wheel tire specifications | / | 10.0/80-18 |
Driving wheel track | mm | 1550 |
Driving wheel tire specifications | / | 400/70R24 |
Wheelbase | mm | 2355 |
Operating speed range | km/h | ≤7 |
Design cutting length | mm | 20 |
