Silage Making Machine
Product introduction:
☆ The whole machine has a compact structure, small turning radius, easy operation and reliable quality.
☆ Feeding assembly: Four-roller feeding chamber, segmented design, can achieve quick hook-up, horizontal clamping feeding device, improves the reliability of the whole machine and makes maintenance more convenient.
☆ Shredding assembly: 18 double-row herringbone-shaped moving knives, integrated spindle design, fixed knives with double-edged design, reversible replacement, and standard automatic sharpening.
☆ Powertrain: Quanchai 220 horsepower engine, PTO intelligent fuel-saving control, with light load, medium load, heavy load switching function, four-wheel drive system, etc.
Product Details:
This silage harvester is independently developed and produced by our company. After years of practice and the perfect combination of the latest technology, the machine has a novel design and can fully realize non-row harvesting. At present, it has become a silage harvester with leading technology and complete functions in China. It can complete multiple operations of silage crops at one time, such as cutting off the ground, sequential feeding, uniform chopping, grain crushing, throwing and loading.
Product parameter:
Projects | unit | Design value |
Model Name | / | 4QZ-2100 Self-propelled Green Forage Harvester |
Form of Construction (Hook-up) | / | Self-propelled |
Working condition external dimensions (L*W*H) | mm | 5560*2200*4000 |
structural quality | kg | 6400 |
Matching power range | kW | 161.5 |
Matching engine rated speed | r/min | 2300 |
Cutting width | mm | 2050 |
Crop collecting header type | / | Straight cutting table |
Header cutter type | / | Disc cutter |
Feeding mechanism type | / | Feeding roller |
Number of feeding mechanisms | / | 4 |
Straw chopping mechanism type | / | Drum type |
Grain crushing mechanism type | Roller type | |
Speed Shift | / | Manual speed shift |
Drive mode | / | Hydraulic drive |
Brake type | / | Disc |
Steering wheel track | mm | 1600 |
Guide wheel tire specifications | / | 10.0/80-18 |
Driving wheel track | mm | 1550 |
Driving wheel tire specifications | / | 400/70R24 |
Wheelbase | mm | 2355 |
Operating speed range | km/h | ≤7 |
Design cutting length | mm | 20 |
